LED Spot Grid High Quality
You are here
LED Spot Grid High Quality
Benefits:
- Available in white, nickel and aluminum
- Significant energy cost is saving
- Low glare, comfortable lighting
- Low energy cost and maintenance cost
Features:
- Up to 80% energy saving compared with halogen grille light
- Well designed structure for glare minimizing
- Same cutout hole as halogen grille light
Validations:
Applications
Hotel
Restaurant
Retail
Technical Data
| Specifications Model |
 |
 |
 |
 |
|---|---|---|---|---|
| MGS08-灵清-双头-4000K-SP-40° | LEDSpotGR-HQ-22 28W | LEDSpotGR-HQ-22 44W | LEDSpotGR-HQ-14 44W | |
| Optical parameters | ||||
| Color Temperature | 4 000K | 2 700K, 3 000K, 4 000K | 2 700K, 3 000K, 4 000K | 2 700K, 3 000K, 4 000K |
| Lumen | 840lm | 1 600lm, 1 680lm, 1 800lm | 2 320lm, 2 400lm, 2 560lm | 2 320lm, 2 400lm, 2 560lm |
| Beam angle | 40° | 24-40 | 24-40 | 24-40 |
| CRI(Ra) | 80 | ≥80 | ≥80 | ≥80 |
| Electrical parameters | ||||
| Input voltage range(VAC) | 220-240 | 220~240 | 220~240 | 220~240 |
| Input frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Input current(A) | 0.09 | 0.21 | 0.16 | 0.16 |
| Efficacy(lm/W) | 60 | ≈60 | ≈55 | ≈55 |
| Rated wattage(W)(Ta 25℃) | 14 | 28.0 | 44.0 | 44.0 |
Packaging information
| Code/Description | Packaging unit | Pieces per unit | Dimensions | Gross weight | Volume |
|---|---|---|---|---|---|
| 6956321845841 | Shipping carton box | 6 | 320 × 175 × 300 mm | 4.5 kg | |
| 6956321845865 | Shipping carton box | 6 | 380 × 255 × 300 mm | 6.2 kg | |
| 6956321845889 | Shipping carton box | 6 | 395 × 340 × 415 mm | 11.5 kg | |
| 6956321845902 | Shipping carton box | 6 | 405 × 265 × 480 mm | 11.5 kg | |
| 6956321845926 | Shipping carton box | 6 | 320 × 175 × 300 mm | 4.5 kg | |
| 6956321845940 | Shipping carton box | 6 | 380 × 255 × 300 mm | 6.2 kg | |
| 6956321845964 | Shipping carton box | 6 | 395 × 340 × 415 mm | 11.5 kg | |
| 6956321845988 | Shipping carton box | 6 | 405 × 265 × 480 mm | 11.5 kg |
